Features and Benefits
● The overlapping plate of the German unloading platform is made of a whole piece of ultra-thick 16mm patterned steel plate, with a specially designed bending angle to prevent the "trailer chassis" of the material handling equipment on the loading and unloading trailer compartment. The overlap width is 500, and the trapezoidal design can meet the needs of vehicles with different carriage widths.
● Main platform: The panel is made of 8mm thick embossed anti-slip steel plate. The lower support structure is C-shaped anti-torsion steel. Anti-tensile ribs are set at both ends to prevent the main board from stretching and deforming.
● The overlap plate and main cylinder adopt double-acting cylinders to meet the requirements of unloading operations for fully loaded vehicles.
● Standard configuration of operator protection system to prevent accidents.
● Constant voltage control allows the operator to control the platform movement at all times. Stationary/working lap descents are safer.
● Environmentally friendly - uses degradable anti-wear hydraulic oil.
● Control system The integrated control system completely integrates the loading and unloading platform, platform door and inflatable door seal into one control unit, which is intuitive, clear and easy to operate. Electrical control box 24V low voltage control, IP65 rating
